MG330-5.0 PCB SCREW TERMINAL BLOCK

MG330-5.0
PCB SCREW TERMINAL BLOCK

0
Views: 54
Contact us

Product parameters

 认证  APPROVAL

 材质及电镀  MATERIAL
 间距 5.0MM  Pitch 5.0MM
 极数 2P、3P  Poles 2P、3P
螺丝 M2.5、钢、镀锌 Screws M2.5、Steel、Zinc Plated
簧片 磷青铜、镀镍 Wire guard Phosphor bronze、Ni plated
 焊针 黄铜、镀锡  Pin Header Brass、Tin Plated
 塑件  PA66.UL94V-0  Housing  PA66.UL94V-0

 电气性能    ELECTRICAL
 额定电压  300V  Rated voltage  300V
 额定电流 15A  Rated current 15A
 耐电压  AC2000V/1Min  Withstanding Voltage   AC2000V/1Min
使用线径 22-12AWG Wire range 22-12AWG

 机械性能    MECHANICAL
 温度范围 -30℃~+120℃  Temp.Range -30℃~+120℃
 瞬时温度  +250℃5秒  MAX soldering  +250℃ for 5 sec.
扭矩 0.4Nm(3.5lb.in) Torque 0.4Nm(3.5lb.in)
剥线长度 5-7mm Strip length 5-7mm



DRAWING DOWNLOAD
