MG237-5.08 PCB SPRING TERMINAL BLOCK Wholesale

MG237-5.08 PCB SPRING TERMINAL BLOCK

MG237-5.08
PCB SPRING TERMINAL BLOCK

0
Views: 383
Contact us

Product parameters

 材质及电镀  MATERIAL
 间距 5.08MM  Pitch 5.08MM
 极数 2P-24P  Poles 2P-24P
焊针 黄铜、镀锡 Contact Brass、Tin Plated
弹片 不锈钢 Clips Stainless steel
 塑件  PA66.UL94V-0  Housing  PA66.UL94V-0

 电气性能    ELECTRICAL
 额定电压 300V  Rated voltage 300V
 额定电流 10A  Rated current 10A
 耐电压 AC2500V/1Min  Withstanding Voltage  AC2500V/1Min
 使用线径 22-16AWG  Wire range 22-16AWG

 机械性能    MECHANICAL
 温度范围 -40℃~+105℃  Temp.Range -40℃~+105℃
 瞬时温度  +250℃5秒  MAX soldering  +250℃ for 5 sec.
 剥线长度 10mm  Strip length 10mm



DRAWING DOWNLOAD
