MH136HT-10.16 PCB SCREW TERMINAL BLOCK

MH136HT-10.16
PCB SCREW TERMINAL BLOCK

0
Views: 116
Contact us

Product parameters


 材质及电镀  MATERIAL
 间距 10.16MM  Pitch 10.16MM
 极数 1P-XXP  Poles 1P-XXP
螺丝 M4、钢、镀锌 Screws M4、钢、镀锌
方扣 黄铜、镀镍 Wire cage Brass、Ni Plated
焊针 黄铜、镀锡 Pin Header Brass、Tin Plated
 塑件  PA66.UL94V-0  Housing  PA66.UL94V-0

 电气性能    ELECTRICAL
 额定电压  1000V  Rated voltage 1000V
 额定电流 65A  Rated current 65A
 耐电压  AC3500V/1Min  Withstanding Voltage   AC3500V/1Min
使用线径 20-6AWG Wire range 20-6AWG

 机械性能    MECHANICAL
 温度范围 -40℃~+105℃  Temp.Range -40℃~+105℃
 瞬时温度  +250℃5秒  MAX soldering  +250℃ for 5 sec.
剥线长度 10mm Strip length 10mm



DRAWING DOWNLOAD
