HT396V-3.96 PLUG-IN TERMINAL BLOCK Wholesale

HT396V-3.96 PLUG-IN TERMINAL BLOCK

HT396V-3.96
PLUG-IN TERMINAL BLOCK

0
Views: 1,307
Contact us

Product parameters

 材质及电镀  MATERIAL
 间距 3.96MM  Pitch 3.96MM
 极数 2P-12P  Poles 2P-12P
 焊针 黄铜、镀锡  Pin Header Brass、Tin Plated
 塑件  PA66.UL94V-0  Housing  PA66.UL94V-0

 电气性能    ELECTRICAL
 额定电压  300V  Rated voltage  300V
 额定电流 10A  Rated current 10A
 耐电压  AC1500V/1Min  Withstanding Voltage   AC1500V/1Min

 机械性能    MECHANICAL
 温度范围 -40℃～+105℃  Temp.Range -40℃～+105℃
 瞬时温度  +250℃5秒  MAX soldering  +250℃ for 5 sec.



DRAWING DOWNLOAD
