MG105V-5.0/7.5 PCB SCREW TERMINAL BLOCK

MG105V-5.0/7.5
PCB SCREW TERMINAL BLOCK

0
Views: 122
Contact us

Product parameters


 材质及电镀  MATERIAL
 间距 5.0/7.5MM  Pitch 5.0/7.5MM
 极数 1P-XXP  Poles 1P-XXP
螺丝 M2.5、钢、镀镍 Screws M2.5、Steel、Ni Plated
方扣 钢、镀锌或黄铜、镀镍 Wire cage Steel、Zinc plaed or Brass、Ni plated
 焊针 黄铜、镀锡  Pin Header Brass、Tin Plated
 塑件  PA66.UL94V-0  Housing  PA66.UL94V-0

 电气性能    ELECTRICAL
 额定电压  300V  Rated voltage  300V
 额定电流 24A  Rated current 24A
 耐电压  AC2500V/1Min  Withstanding Voltage   AC2500V/1Min
使用线径 24-14AWG Wire range 24-14AWG

 机械性能    MECHANICAL
 温度范围 -40℃~+105℃  Temp.Range -40℃~+105℃
 瞬时温度  +250℃5秒  MAX soldering  +250℃ for 5 sec.
扭矩 0.4Nm(3.5lb.in) Torque 0.4Nm(3.5lb.in)
剥线长度 9mm Strip length 9mm



DRAWING DOWNLOAD
