MG250/2.5/3.5/5.0/7.0 PCB SPRING TERMINAL BLOCK

MG250/2.5/3.5/5.0/7.0
PCB SPRING TERMINAL BLOCK

0
Views: 1,334
Contact us

Product parameters

 认证  APPROVAL

 材质及电镀  MATERIAL
 间距 2.5/2.54/3.5/7.0MM  Pitch 2.5/2.54/3.5/7.0MM
 极数 1P-XXP  Poles 1P-XXP
焊针 磷青铜、镀锡 Contact Phosphor bronze、Tin Plated
弹片 不锈钢 Clips Stainless steel
 塑件  PA66.UL94V-0  Housing  PA66.UL94V-0

 电气性能    ELECTRICAL
 额定电压 300V  Rated voltage 300V
 额定电流 7A  Rated current 7A
 耐电压 AC2500V/1Min  Withstanding Voltage  AC2500V/1Min
 使用线径 22-18AWG  Wire range 22-18AWG

 机械性能    MECHANICAL
 温度范围 -40℃~+105℃  Temp.Range -40℃~+105℃
 瞬时温度  +250℃5秒  MAX soldering  +250℃ for 5 sec.
 剥线长度 8-9mm  Strip length 8-9mm
