MG360-7.5 PCB SCREW TERMINAL BLOCK

MG360-7.5
PCB SCREW TERMINAL BLOCK

0
Views: 251
Contact us

Product parameters


 材质及电镀  MATERIAL
 间距 7.5MM  Pitch 7.5MM
 极数 2P、3P,4P-30P  Poles 2P、3P,4P-30P
螺丝 M2.5、钢、镀镍 Screws M2.5、Steel、Ni Plated
弹片 不锈钢 Clips Stainless steel
焊针 黄铜、镀锡 Pin Header Brass、Tin Plated
 塑件  PA66.UL94V-0  Housing  PA66.UL94V-0

 电气性能    ELECTRICAL
 额定电压 250V  Rated voltage  250V
 额定电流 16A  Rated current 16A
 耐电压  AC2000V/1Min  Withstanding Voltage   AC2000V/1Min
使用线径 22-14AWG Wire range 22-14AWG

 机械性能    MECHANICAL
 温度范围 -33℃~+120℃  Temp.Range -33℃~+120℃
 瞬时温度  +250℃5秒  MAX soldering  +250℃ for 5 sec.
剥线长度 5-6mm Strip length 5-6mm



DRAWING DOWNLOAD
